Model
TP1.1K
TP1.3K
TP1.6K
TP2.0K
TP4130
8Ω Stereo power(RMS)
2×1100W
2×1300W
2×1600w
2×2000W
4x1300W
4Ω Stereo power(RMS)
2×1800W
2×2200W
2×2600w
2×3600W
4X2200W
2Ω Stereo power(RMS)
2x2200W
2x2600W
2x3200W
2x4500W
4x2400W
Imput Impedance
20KΩ Balanced10KΩ Unbalanced
Frequency Response
20Hz-25KHz ±0.5dB
THD+N (Rated power)
4Ω /Khz %:0.1%
Damping Factor
500
S/N(broad band width)
100dB
Amplifier gain selectable
-5dB,-4dB,-2dB,0dB
Power requirement
200-240V-50-60Hz
Minimun power up voltage
180-260-50-60Hz
Dimension HWD(mm)
88x483x439
95x483x378
Shipping HWD(mm)
140×550×560(0.04CBM)
145x575x555(0.05CBM)
Net Weight(KG)
12.5
12.8
13
13.5
Gross Weight(KG)
14
14.3
14.5
15
17
